VENTURA TRUCK LOADING AND UNLOADING WITH FLEXIBLE ROLLER CONVEYOR
VENTURA TLUC
Description:
| CONVEYOR TYPE & CONSTRUCTION | ||
| Conveyor Type | Flexible / Expandable Gravity or Powered Roller Conveyor | Flexible design allows the conveyor to expand, contract and curve according to the required material flow path. |
| Conveyor Frame | Heavy-duty, powder-coated steel or stainless steel | Provides durable construction suitable for demanding loading, unloading and material-handling environments. |
| Roller Type | Zinc-Plated Steel / PVC / Rubber-Coated Rollers Optional |
Multiple roller materials allow configuration according to the product and application. |
| Roller Diameter | 38 mm / 50 mm / 60 mm Depending on model |
Different roller diameters provide flexibility for various load and conveyor configurations. |
| Conveyor Width | 500 mm / 600 mm / 800 mm Customizable |
Customizable width supports different carton and package sizes. |
| DIMENSIONS & LOAD HANDLING | ||
| Conveyor Height | Adjustable, typically 600–1000 mm | Adjustable height helps match different loading docks, workstations and truck-bed levels. |
| Conveyor Length | Expandable Example: 3 m contracted → 9 m fully extended |
Expandable length provides flexibility for truck loading, unloading and changing work layouts. |
| Load Capacity | Up to 50–100 kg/m Depending on roller and frame type |
Supports the specified load range based on the selected conveyor configuration. |
| Roller Pitch (Spacing) | 100–150 mm | Suitable roller spacing supports smooth movement of cartons and packages. |
| Turning Radius | Highly Flexible Capable of 180° curves and zig-zag paths |
Allows the conveyor route to be adapted to changing warehouse and loading-area layouts. |
| DRIVE & OPERATION | ||
| Drive Option | Gravity or Motorized AC Motor / DC Motor with Speed Control |
Offers a choice between gravity-fed movement and powered material transfer. |
| Brake System | Optional Roller Brakes or Friction Rollers | Helps control package movement and conveyor speed when required. |
| End Stopper | Optional Carton Stop / Guide At loading or unloading point |
Provides controlled positioning of cartons at loading and unloading points. |
| MOBILITY & ENVIRONMENT | ||
| Mobility | Lockable Casters | Heavy-duty wheels provide easy relocation while the brakes help maintain stability during operation. |
| Temperature Range | -5°C to 45°C | Specified operating range for the conveyor system. |
| CUSTOMIZATION & MAINTENANCE | ||
| Customization | Length, Width, Height, Roller Material and Motor Configuration | Allows the conveyor to be configured according to specific operational and layout requirements. |
| Maintenance | Simple Mechanical System, Especially Gravity Version | Simple construction with fewer moving parts helps support low-maintenance operation. |
