| MACHINE PERFORMANCE & PALLET HANDLING |
| Travel Speed |
90 m/min |
High travel speed supports faster movement between pallets and improves packaging-line productivity. |
| Maximum Pallet Size |
Any Size |
Provides flexibility for handling different pallet dimensions. |
| Minimum Pallet Size |
600 × 600 mm |
Suitable for wrapping smaller palletized loads while maintaining machine flexibility. |
| Maximum Wrapping Height |
2,400 mm (Optional 2,800 mm) |
Accommodates tall pallet loads with an optional higher wrapping configuration. |
| FILM WRAPPING SYSTEM |
| Film Stretch |
Pre-Stretch – Up to 300%; Anti-Stretch – Up to 200% |
Provides flexible film application according to load stability and packaging requirements. |
| Film Tension |
Adjustable |
Allows wrapping tension to be optimized for different products and load conditions. |
| Maximum Film Specification |
250 mm |
Supports the specified film size for efficient and consistent wrapping. |
| Film Carriage |
Chain driven film carriage |
Provides reliable film carriage movement and consistent film application. |
| Film System Options |
Available with Pre-Stretch & Anti-Stretch |
Allows the wrapping system to be selected according to application and film usage requirements. |
| ELEVATOR & WRAPPING CONTROL |
| Elevator Unit Speed |
Adjustable |
Allows vertical film application speed to be matched with different load heights. |
| Pallet Height Detection |
Sensor detects pallet height with up and down program |
Automatically adapts the wrapping movement to the pallet height for consistent coverage. |
| Top & Bottom Layers |
Adjustable |
Provides greater control over wrapping coverage and load stability. |
| Robot Speed |
Adjustable |
Enables the operator to select an appropriate movement speed for different wrapping applications. |
| OPERATION & SAFETY |
| Soft Start |
Yes |
Provides smooth machine acceleration and helps reduce sudden movement during operation. |
| Emergency Stop |
Yes |
Allows immediate machine stoppage when an emergency situation occurs. |
| Battery System |
Battery charger and battery indicator |
Supports convenient operation and allows the operator to monitor battery status. |
| Detecting Wheel |
320 mm diameter |
Provides reliable contact and detection while the machine moves around the pallet. |
| MACHINE DIMENSIONS & WEIGHT |
| Machine Size (L × W × H) |
1,906 × 1,225 × 2,943 mm |
Compact mobile configuration helps optimize floor-space utilization around the packaging area. |
| Machine Net Weight |
430 kg |
Provides a stable machine structure while remaining suitable for mobile wrapping applications. |
