| MACHINE & STRAPPING SYSTEM |
| Machine Type |
Semi-Automatic Low Bed Strapping Machine |
Low-bed configuration is suitable for efficient strapping of heavy and bulky packages. |
| Model |
VENTURA 900L |
Dedicated low-bed model designed for practical and reliable packaging operations. |
| Strap Type |
PP (Polypropylene) Strap |
Provides an economical and reliable strapping solution for a wide range of packages. |
| Strap Width |
6 – 15 mm (Adjustable) |
Supports different PP strap widths according to package and application requirements. |
| Strapping Speed |
Approximately 2 seconds per strap |
Fast cycle time improves packaging productivity. |
| Tension Range |
10 – 60 kg (Manual or knob adjustment) |
Allows tension to be adjusted according to package weight and strap type. |
| Sealing Method |
Heat Welding |
Provides consistent and reliable sealing of PP straps. |
| LOW BED DESIGN & OPERATION |
| Table Height |
Approximately 400 mm – Low Bed Design |
Low working height makes loading and strapping of heavy packages more convenient. |
| Operation Mode |
Manual strap insert + push button / foot pedal |
Simple operation allows flexible control according to operator preference. |
| KEY FEATURES |
| Reduced Strap Bending |
Low bending radius design |
Helps protect the strap from cracks or damage during sealing. |
| Suitable for Thin Straps |
Suitable for narrow and thinner PP straps such as 6 mm and 9 mm |
Provides greater flexibility for applications requiring smaller strap sizes. |
| Smooth Strap Feeding |
Enhanced strap feeding system |
Ensures consistent strap movement and helps minimize feeding-related jams. |
| Adjustable Tension Control |
Precise manual tension adjustment |
Allows suitable strap tension to be selected for different package weights and strap types. |
| Fast Cycle Time |
Typically 1.5 – 3 seconds per strap |
Supports efficient and productive strapping operations. |
| Durable Construction |
Robust frame with corrosion-resistant components |
Provides reliable construction for long-term packaging operation. |
| User-Friendly Operation |
Simple interface with easy strap loading and maintenance access |
Reduces operator effort and simplifies routine maintenance. |
| Energy Efficiency |
Auto shut-off and low power consumption during idle periods |
Helps reduce unnecessary energy consumption during machine downtime. |
| POWER & MACHINE SPECIFICATIONS |
| Power Supply |
220 V, Single Phase, 50/60 Hz |
Suitable for standard single-phase electrical supply. |
| Power Consumption |
0.5 – 1.0 kW |
Supports economical machine operation with controlled power consumption. |
| Machine Dimensions (L × W × H) |
Approximately 900 × 580 × 400 mm |
Compact low-bed dimensions help save valuable packaging-floor space. |
