MACHINE & STRAPPING SYSTEM
|
|
Machine Type
|
Fully Automatic Strapping Machine
|
Designed for continuous, high-efficiency carton and box strapping without manual intervention.
|
|
Model
|
VENTURA 1200 PR – Heavy Duty
|
Heavy-duty configuration designed for reliable continuous packaging operations.
|
|
Strap Size
|
9 mm, 12 mm or 15 mm
|
Supports multiple strap sizes for different carton and package strapping requirements.
|
|
Load Bearing Capacity
|
100 kg
|
Suitable for cartons and packages within the specified load capacity.
|
|
Arch Size
|
800 mm (W) × 600 mm (H)
|
Provides a suitable opening for a wide range of carton and box sizes.
|
|
AUTOMATION & OPERATION
|
|
Operation
|
Fully Automatic / Unmanned Operation
|
Enables automatic package detection, conveying and strapping with minimal operator intervention.
|
|
Item Detection
|
Photoelectric sensors with automatic conveying
|
Automatically detects packages and supports smooth continuous strapping.
|
|
PLC Control
|
PLC system such as Siemens or Mitsubishi
|
Provides reliable programmable control for stable automated packaging performance.
|
|
Packing Speed
|
2.0 seconds / cycle
|
Fast cycle time helps increase packaging productivity and reduce labour time.
|
|
CONVEYING & CUSTOMIZATION
|
|
Conveying System
|
Power roller variants available
|
Provides smooth carton movement and supports integration with automated packaging lines.
|
|
Table Height
|
750 mm
|
Suitable working height for integration with production and packaging conveyors.
|
|
Customization
|
Standard frame around 800 × 600 mm; customizable according to requirements
|
Allows the machine configuration to be adapted to specific production requirements.
|
|
ELECTRICAL & MACHINE SPECIFICATIONS
|
|
Power Supply
|
415 V / 50 Hz / 1.4 kW / 3 Phase
|
Industrial three-phase power configuration for reliable continuous operation.
|
|
Electrical Components
|
LG PLC, French TE, Japanese OMRON & MCN, photoelectric switch controls
|
Specified industrial electrical components support dependable machine operation.
|
|
Machine Dimensions
|
1680 mm (L) × 700 mm (W) × 1500 mm (H)
|
Compact dimensions help optimize available production floor space.
|
|
Machine Weight
|
300 kg
|
Provides a stable machine platform for continuous strapping operations.
|
|
KEY CUSTOMER BENEFITS
|
|
Unmanned Operation
|
Automatic detection, conveying and strapping
|
Reduces manual handling and supports continuous automated packaging.
|
|
High Efficiency
|
2.0 seconds per cycle
|
Helps improve production throughput while saving time and labour cost.
|
|
Automated Line Integration
|
Power roller conveying and automated production-line compatibility
|
Ideal for integration with automated carton handling and packaging systems.
|
|
Heavy Duty Performance
|
Heavy-duty machine configuration with customizable design
|
Suitable for demanding continuous packaging environments and customized production requirements.
|
