MACHINE & CARTON HANDLING
|
| Machine Type |
Fully Automatic Carton Sealing Machine (Auto Adjustable Side & Top Drive) |
Automatically adjusts the sealing system to accommodate different carton sizes for continuous packaging. |
| Drive System |
Auto-adjusting side and top tape heads with servo or motorized drive |
Provides precise tape head movement for consistent carton sealing. |
| Carton Size Range |
L: 150–600 mm × W: 150–600 mm × H: 100–600 mm |
Handles a wide range of carton sizes for flexible packaging applications. |
| Carton Height Adjustment |
Automatic — accommodates variable carton heights without manual change |
Reduces manual setup and supports faster product changeovers. |
|
TAPE & SEALING PERFORMANCE
|
| Tape Type & Width |
BOPP or Kraft Tape; Width: 48 mm or 72 mm |
Provides flexibility to use different tape types and widths for various packaging requirements. |
| Tape Thickness |
38–55 microns |
Supports the specified tape thickness range for reliable sealing. |
| Tape Tension Control |
Electronically adjustable tension control |
Maintains consistent tape tension for uniform sealing quality. |
| Sealing Speed |
Up to 25–30 cartons per minute |
High-speed operation helps increase production efficiency. |
|
CONTROL & AUTOMATION
|
| Control System |
PLC with Touchscreen HMI and Memory Function |
Simplifies operation, monitoring and parameter adjustment while allowing multiple settings to be stored. |
| Automatic Carton Size Detection |
Optical sensors detect carton size and adjust tape heads automatically |
Eliminates manual setup when changing between different carton sizes. |
| Adjustable Conveyor Speed |
Integrated variable-speed conveyor system |
Synchronizes carton flow with upstream and downstream packaging equipment. |
| Memory Function |
Stores multiple carton size parameters |
Enables quick switching between different carton sizes and packaging requirements. |
| User Interface |
User-friendly Touchscreen HMI |
Provides intuitive access to operation, troubleshooting and parameter adjustments. |
|
CONSTRUCTION & SAFETY
|
| Frame Material |
Heavy-duty powder-coated steel frame |
Provides durable construction for demanding industrial environments. |
| Safety Features |
Emergency stop, safety guards and overload protection |
Helps protect operators and equipment during operation. |
| Noise Level |
Below 70 dB(A) |
Supports comparatively low-noise machine operation. |
| Operating Temperature Range |
0°C to 40°C |
Specified operating range for dependable machine performance. |
|
MACHINE SPECIFICATIONS
|
| Power Supply |
220 V / 50 Hz Single Phase or 380 V / 50 Hz 3 Phase |
Provides flexible electrical configuration options for different installations. |
| Machine Dimensions |
Approx. L 1400 mm × W 900 mm × H 1500 mm |
Compact footprint helps optimize available production floor space. |
| Machine Weight |
Around 180–220 kg |
Robust machine construction suitable for automated carton sealing applications. |
| Tape Loading System |
Quick-load tape system with automatic detection |
Simplifies tape replacement and helps minimize machine downtime. |
| Maintenance |
Tool-free access panels and modular components |
Provides easier access for servicing and helps reduce maintenance time. |
