MACHINE & CARTON HANDLING
|
| Machine Type |
Fully Automatic Carton Sealing Machine with Auto Flap Closer (Side & Top Drive) |
Automatically closes carton flaps and seals cartons for continuous packaging operation. |
| Drive System |
Auto-adjusting side and top tape heads with motorized/servo drives |
Automatically adapts the sealing heads to different carton sizes without frequent manual adjustment. |
| Carton Size Range |
L: 150–600 mm × W: 150–600 mm × H: 100–600 mm |
Handles a wide range of carton dimensions for flexible production requirements. |
| Carton Height Adjustment |
Automatic — handles variable carton heights without manual setup |
Reduces setup time and allows mixed carton sizes to be processed efficiently. |
|
TAPE & SEALING PERFORMANCE
|
| Tape Type & Width |
BOPP or Kraft Tape; 48 mm or 72 mm |
Supports commonly used carton sealing tapes for reliable package closure. |
| Tape Thickness |
38–55 microns |
Compatible with the specified tape thickness range for consistent sealing. |
| Tape Tension Control |
Electronically adjustable |
Provides consistent tape tension for secure and uniform carton sealing. |
| Sealing Speed |
Up to 25–30 cartons per minute |
High-speed sealing supports fast-paced production and packaging lines. |
|
CONTROL & AUTOMATION
|
| Control System |
PLC with Touchscreen HMI and Memory Function |
Enables easy operation, real-time monitoring and convenient parameter management. |
| Flap Closing System |
Automatic flap folding mechanism with adjustable guides |
Precisely folds carton flaps before sealing for consistent package closure. |
| Sensors |
Optical Sensors for carton presence, flap detection and size |
Automatic detection improves flap folding accuracy and tape placement. |
| Conveyor System |
Integrated variable-speed conveyor |
Synchronizes carton movement for smooth and continuous packaging. |
|
MACHINE CONSTRUCTION & SAFETY
|
| Frame Material |
Heavy-duty powder-coated steel frame |
Robust construction provides durability for industrial packaging environments. |
| Safety Features |
Emergency stop, safety guards and overload protection |
Helps protect operators and equipment during machine operation. |
| Noise Level |
Below 70 dB(A) |
Designed for comparatively low-noise operation. |
| Operating Temperature Range |
0°C to 40°C |
Specified operating range for dependable machine performance. |
|
POWER & MACHINE SPECIFICATIONS
|
| Power Supply |
220 V / 50 Hz Single Phase or 380 V / 50 Hz 3 Phase |
Flexible electrical configurations support different industrial installation requirements. |
| Machine Dimensions |
Approx. L 1600 mm × W 1000 mm × H 1600 mm |
Compact industrial footprint helps optimize available production space. |
| Machine Weight |
Around 200–250 kg |
Suitable for a robust automated carton sealing setup. |
|
OPERATION & MAINTENANCE
|
| Tape Loading System |
Quick-load tape system with automatic tape end detection |
Simplifies tape replacement and helps reduce downtime. |
| Maintenance |
Tool-free access panels and modular components |
Easy access supports faster servicing and maintenance. |
| Energy Saving |
Automatic standby mode during idle periods |
Helps reduce unnecessary energy consumption when the machine is not actively sealing cartons. |
